XCMG Oil Pressure Alarm Switch 803502505

1 Z3.4.1(徐桥) 接管 Connector

2 GB5782-86 螺栓 M16×80 Bolt

3 GB6182-86 锁紧螺母 M16 Lock Nut

4 GB93-87 垫圈 16 Lock Washer

5 GB97.1-85 垫圈 16 Washer

6 Z3.4-1 螺栓 M12×40 Bolt

7 GB93-87 垫圈 12 Lock Washer

8 GB6181-86 螺母 M12 Nut

9 GB91-86 销 3.2×22 Pin

10 Z3.4.2 主传动轴 Main Driving Shaft

11 LW330F.8.1 后车架 Rear Chassis

12 Z3.4-2 螺栓 M14×45 Bolt

13 GB93-87 垫圈 14 Lock Washer

14 GB6181-86 螺母 M14 Nut

15 GB91-86 销 3.2×26 Pin

16 Z3.4.3 前传动轴 Front Transmission Shaft

17 Z3.4-3 螺栓 M14×56 Bolt

18 Z3.4.4A 后传动轴 Rear Axle Transmission Shaft

19 Z3.4-4 垫片 Shim
