1 300F.05.1A 前车架 Front Chassis
2 300F.05.3 动臂缸销 Lift Cylinder Pin
3 JB/T7940.1-1995 油杯 M10×1 Crease Cup
4 GB5783-86 螺栓 M16×25 Bolt
5 GB93-87 垫圈 16 Washer
6 GB97.1-85 垫圈 16 Washer
7 GB5783-86 螺栓 M8×20 Bolt
8 GB93-87 垫圈 8 Lock Washer
9 LW330F(II).08.12 右前大灯架 Front Lamp Bracket(R)
10 320E.8.3 转斗缸后销轴 Tilt Cylinder Pin Shaft
11 GB97.1-85 垫圈 8 Washer
12 GB5783-86 螺栓 M8×20 Washer
13 LW320F(I).18.2 前罩板 Front Cover Plate
14 LW330F(II).08.11 左前大灯架 Front Lamp Bracket(L)
15 300F.05.2 动臂销 Lift Arm Pin
16 85Z.7-15 弹簧销 Spring Pin
17 85Z.7-12 连杆 Lock Link
18 GB882-86 销 B32×70 Pin
19 GB5783-86 螺栓 M10×20 Bolt
20 Z3.8-13 垫圈 Washer
21 GB93-87 垫圈 10 Lock Washer
22 320E.8.4 前转向销 Front Steering Pin
23 JB982-77 垫圈 10 Lock Washer
24 ZL40.8.4-1 通油螺栓 Bolt
25 Z3.8.12.1 注油管 Oil Injecting Tube
26 GB5785-86 螺栓 M24×2×240 Bolt
27 GB6176-86 螺母 M24×2 Nut
28 GB93-87 垫圈 24 Lock Washer
1 | 300F.05.1A | 前车架 | Front Chassis |
2 | 300F.05.3 | 动臂缸销 | Lift Cylinder Pin |
3 | JB/T7940.1-1995 | 油杯 M10×1 | Crease Cup |
4 | GB5783-86 | 螺栓 M16×25 | Bolt |
5 | GB93-87 | 垫圈 16 | Washer |
6 | GB97.1-85 | 垫圈 16 | Washer |
7 | GB5783-86 | 螺栓 M8×20 | Bolt |
8 | GB93-87 | 垫圈 8 | Lock Washer |
9 | LW330F(II).08.12 | 右前大灯架 | Front Lamp Bracket(R) |
10 | 320E.8.3 | 转斗缸后销轴 | Tilt Cylinder Pin Shaft |
11 | GB97.1-85 | 垫圈 8 | Washer |
12 | GB5783-86 | 螺栓 M8×20 | Washer |
13 | LW320F(I).18.2 | 前罩板 | Front Cover Plate |
14 | LW330F(II).08.11 | 左前大灯架 | Front Lamp Bracket(L) |
15 | 300F.05.2 | 动臂销 | Lift Arm Pin |
16 | 85Z.7-15 | 弹簧销 | Spring Pin |
17 | 85Z.7-12 | 连杆 | Lock Link |
18 | GB882-86 | 销 B32×70 | Pin |
19 | GB5783-86 | 螺栓 M10×20 | Bolt |
20 | Z3.8-13 | 垫圈 | Washer |
21 | GB93-87 | 垫圈 10 | Lock Washer |
22 | 320E.8.4 | 前转向销 | Front Steering Pin |
23 | JB982-77 | 垫圈 10 | Lock Washer |
24 | ZL40.8.4-1 | 通油螺栓 | Bolt |
25 | Z3.8.12.1 | 注油管 | Oil Injecting Tube |
26 | GB5785-86 | 螺栓 M24×2×240 | Bolt |
27 | GB6176-86 | 螺母 M24×2 | Nut |
28 | GB93-87 | 垫圈 24 | Lock Washer |
